Most control problems involve systems that are either partially
unknown or whose true nature varies over time. Modern robust control
methods offer theory and techniques for analyzing and designing
controllers with guarantees of stability, but such robust controllers
are by necessity less aggressive than they could be if full knowledge
of the system were available.
Our approach is to add to the robust control framework a family of
reinforcement learning algorithms based on artificial neural networks
and designed to optimize the performance of a controller through
experience with the actual system. We have showed through
analysis and experiments that stability can be guaranteed even as the
agent learns. This is some of the first work we know of to address
K. Narendra's call for new approaches: "It is precisely in problems
where the system has to adapt to large uncertainty that controllers
based on neural networks will be needed in practical applications. For
such problems, new concepts and methods based on stability theory will
have to be explored." (Narendra, 1990)
The objectives of our current work are the following:
Our work will
ultimately lead to procedures by which an initial robust controller is
designed with as much knowledge of the system to be controlled as is
available, but whose performance is optimized through interactions
with the actual system, complete with guarantees of stability while
learning! The significance to the reinforcement learning field is one
very important to control engineers who require guarantees that a
learning approach will not injure people or systems. Also of practical
importance is the initial robust controller which alleviates a common
complaint about the tremendously long times needed for a reinforcement
learning agent to acquire a good policy. Our learning agent must only
learn the unknown or changing parts of the system. The significance to
the control of energy systems in buildings is that robust MIMO
controller design results in control strategies that vary multiple
actuators to minimize energy cost while maximizing tracking
performance in ways that are impossible with the single-input,
single-output (SISO) approach common in modern HVAC systems. For an
energy system of complexity adequate for a building, it is impossible
to have a complete model of the system, so an approach like our robust
reinforcement learning approach is necessary to fine-tune the control
strategy for the true system and to track changes over time.
- Verify our multi-input, multi-output (MIMO)
robust reinforcement learning approach on our experimental heating,
ventilating, and air-conditioning (HVAC) system,
- Develop new analysis
tools and algorithms to include learned, dynamic models based on
recurrent neural networks within our robust reinforcement learning
theory and techniques,
- Design and test more advanced robust
reinforcement learning algorithms with reinforcement as a function of
control performance plus robustness,
- Evaluate our new techniques with
experiments on the experimental HVAC system,
- Disseminate our
theoretical and experimental results and algorithms through conference
and journal publications and by assisting colleagues at other
institutions in conducting their own tests of our methods,
- Incorporate the results of our research in our teaching. The
significance of this work to the robust control field is the
combination of reinforcement learning and robust control to overcome
the conservative behavior of robust controllers.
We are an
interdisciplinary team consisting of a specialist in
robust control from the Electrical & Computer Engineering Department,
a specialist in reinforcement learning for neural networks from the
Department of Computer Science, and a specialist in design, modeling
and control of HVAC systems from the Mechanical Engineering
Department. This interdisciplinary approach will further advance the
state-of-the-art in the theory of robust reinforcement learning
control design, demonstrate these new methods on an experimental HVAC
system and provide much needed improved methods for controlling HVAC
systems in buildings. Eventual wide spread implementation of these
schemes in buildings around the world will reduce energy consumption,
improve comfort, and extend equipment life.
